320 S EL DORADO | Mesa, AZ 85202
Engine and transmission Displacement 1084.0 ccm (66.15 cubic inches) Engine type Twin, four-stroke Power 101.0 HP (73.7 kW)) @ 7500 RPM Torque 105.0 Nm (10.7 kgf-m or 77.4 ft.lbs) @ 6250 RPM Compression 10.1:1 Bore x stroke 92.0 x 81.5 mm (3.6 x 3.2 inches) Valves per cylinder 4 Fuel system Injection. PGM-FI electronic fuel injection (throttle by wire) Fuel control Single Overhead Cams (SOHC) Ignition Full transistorized ignition Cooling system Liquid Gearbox 6-speed Transmission type Chain (final drive) Clutch Wet, multi-plate with coil springs, aluminum cam assist and slipper clutch Driveline #525 Chain; 16T/42T Chassis, suspension, brakes and wheels Frame type Steel semi-double cradle type with high-tensile strength steel rear sub-frame Rake (fork angle) 27.5° Trail 113 mm (4.4 inches) Front suspension Showa 45mm nverted telescopic fork Front wheel travel 230 mm (9.1 inches) Rear suspension Pro-Link® system w/ single shock Rear wheel travel 220 mm (8.7 inches) Front tire 90/90-21 Rear tire 150/70-R18 Front brakes Double disc. Switchable ABS. 4-piston calipers and sintered metal pads Diameter 310 mm (12.2 inches) Rear brakes Single disc. Switchable ABS. 2-piston caliper and sintered metal pads. Diameter 256 mm (10.1 inches) Wheels Bridgestone Battlax Adventurecross Physical measures and capacities Weight incl. oil, gas, etc 238.0 kg (524.7 pounds) Seat height 850 mm (33.5 inches) If adjustable, lowest setting. Alternate seat height 870 mm (34.3 inches) If adjustable, highest setting. Overall height 1560 mm (61.4 inches) Overall length 2330 mm (91.7 inches) Overall width 960 mm (37.8 inches) Ground clearance 250 mm (9.8 inches) Wheelbase 1575 mm (62.0 inches) Fuel capacity 24.80 litres (6.55 US gallons) Reserve fuel capacity 4.90 litres (1.29 US gallons) Other specifications Color options Black, Blue Starter Electric Factory warranty 1 year
Delivery to your doorstep! Find local dealers in your area who will bring your newly purchased and freshly cleaned vehicle directly to you.
Information deemed reliable, but not guaranteed. Interested parties should confirm all data before relying on it to make a purchase decision. All prices and specifications are subject to change without notice. Prices may not include additional fees such as government fees and taxes, title and registration fees, finance charges, dealer document preparation fees, processing fees, and emission testing and compliance charges.
